Product Description :-
Functional Specifications:
RFID Protocol: EPC Class1 Gen2, ISO18000-6C
Frequency: (US) 902-928MHz, (EU) 865-868MHz
IC type: Alien Higgs-3
Memory EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Write Cycles: 100,000times
Functionality: Read/write
Data Retantion: Up to 50 Years
Applicable Surface: Metal Surfaces
Read Range :(Fix Reader:ThingMagic FU-M6-E) 145cm - (US) 902-928MHz, on metal145cm - (EU) 865-868MHz, on metal
Read Range :(Handheld Reader: OP9908, R2000) 100cm - (US) 902-928MHz, on metal90cm - (EU) 865-868MHz, on metal
Warranty: 1 Year
Physical Specification:
Size: 18x6mm
Thickness: 2.0mm without IC bump, 3.0mm with IC bump
Material: FR4 (PCB)
Colour: Black (Red, Blue, Green, White)
Mounting Methods
Weight: 1.2g
Environmenal Specification:
IP Rating: IP68
Storage Temperature: -40°? to +150°?
Operation Temperature: -40°? to +100°?
Cerifications: Reach Approved, RoHS Approved, CE Approved
|
